Pocket RVT™
The Pocket RVT™ video receiver provides the flexibility and freedom to receive video and data anywher within the Digital Data link™ (DDL™) network utilizing any USB display device for a wide range of military and commercial applications.
The ultra-compact, lightweight Pocket RVT provides dismounted ground troops direct access to real-time video downlink images and geodata from any DDL equipped platform. Designed for versatility, this pocket-sized module turns any USB display device into a Remote Video Terminal and can to be worn on a tactical vest or utility belt. Pocket RVT can interface with a wrist worn smartphone, vest mounted tablet or virtually any USB end-user display device.
Key Features
Ultra Compact, Lightweight
Easy integration into any Tactical Vest/Utility Belt
Secure Digital and Analog
Multi-Band Reception for Military and Commercial use
USB connection to any end-user device running Apps under Windows, Android, or iOS
PRODUCT SPECS
Frequency Bands • M-Band (M1 & M2, M3 & M4) • C-Band (C1)
Waveforms Supported • SUAS DDL • Analog NTSC Video
Interface • USB Digital Interface • SMA RF Connector • Analog Video output in • H.264 MISB format over USB
Physical and Environmental • Size: 3.25” x 2.2” x 0.75” • Weight: 100 grams (0.22 lb) • Operating Temperature: –40°C to +85°C • Water Resistant • Color: Tan or Black
Power Requirements • USB powered • Input Voltage: 5 volts • Current Draw: 0.7 amps (from 1 or optionally 2 USB ports) • Battery Life: depends on USB source (a 2,000 mAh USB battery will receive for 2.8 hours)
