AT-300 Medium/heavy weight, long en- durance VTOL UAV
(Coming Soon)
Gasoline powered
Fully autonomous flight with auto takeoff and landing.
Day video standard, other cameras, video, and sensor packages optional
Up to 6 hour flight time
1.5km standard telemetry range (long range optional
Length: 3350 mm
Width: 910 mm
Height: 1170 mm
Main rotor diameter: 3300 mm
Tail rotor diameter: 560 mm
Dry weight: 58 Kg
Engine: 313cc 28 HP 2 str. gasoline.
On board Generator: 250 W 12V with batt. backup
Climb rate: 122/m/min (AFCS Limited)
Maximum speed: 160 Km/h (AFCS Limited)
Endurance: More than 6 hours
Maximum payload: 50 Kg
Telemetry: 802.11 based, 800 m LOS
Safety Controller: 2.4 GHz, 800 m LOS, 15KM Max
Flight control software: Fully autonomous flight Auto takeoff and landing Unlimited waypoints with in flight retaking Failsafe “return to home” Long range telemetry* up to 30Km or through 3G network or satellite link
*Standard telemetry: 1.5 Km. Optional telemetry: 3-30 Km. Applies to all models.
