Urban View is an Unmanned Aerial Vehicle that enables you to conduct reconnaissance in remote or arduous terrain. This light-weight, compact, readily-deployable system for IMage INTelligence (IMINT) is ideal for detecting everything from breaks in wiring to pipeline leaks. The complete system comes equipped with Electro-Optical and Infra-Red cameras, capable of detecting people and energy loss from a distance of 500 meters and fits in a backpack. It can be hand launched and recovered in fully autonomous mode.
The system can be deployed for day or night operations with equal ease in the harshest terrain or environment. Urban View is equipped with comprehensive safety features to minimize any accidental damages or injuries to anyone operating the equipment. Its sharp turning radius makes it easy to manoeuvre in low flying or obstructed areas.
Unmanned Aerial Vehicle (UAV) Specifications
Maximum Take off Weight < 2 kgs
Time to assemble < 5 minutes
Operational footprint 1 – 2 soldiers and a backpack
Total weight of the system 15 – 20 kgs
Endurance > 60 minutes
Range > 10 – 15 kms
Propulsion Electric motor with foldable propellers
Power source Rechargeable Li-Po batteries
Launch Hand launch
Recovery Belly landing
Minimum speed 40 kmph
Cruise speed 55 – 60 kmph
Mission capability Fully autonomous
Maximum continuous winds 40 kmph
Life cycle 200 flight landings on rough terrain
Operational altitude 300 to 1,000 ft
Service ceiling 15,000 ft
Wing span 1.5 m
Total length 0.8 m
Climb rate > 4 m/s
