Airframe
2605.3 TTSN
Annual/100 hr. Completed 5/17/17
Completed Section 2A Supplemental Inspection documents
Completed Supplemental Inspection documents Time Limits-Structures 2A-10-00.
Inspection Time Limits Section 2A-10-01.
Inspection Operations Requirements 2A-12-01 thru 2A-12-27, 2A-12-29 thru 2A-12-32.
Engine(s)
Continental O-520-U/TS
Texas Skyways conversion
O time since overhaul/modification STC# SE09773SC
Prop Specs
Hartzell HC-C3YF-1RF and spinner assembly D-5732-P
O time since new
Modifications/Conversions
Installed the following items new:
Texas Skyways Overhauled Modified Engine and New Propeller System. 285 HP, 2400 TBO
ABI Alaskan Bushwheel Tail Wheel and Fork Assembly
AP Enterprises Door Steward Gas Spring Door Assist
BAS Tail Pull Handle in Aft Fuselage Kit
BAS Pilot and Co-Pilot Shoulder Harness System
Brackett Aero Filters Induction Air Filter
Burl’s Aircraft Rebuild Alternate Fuel Outlet Screens
F. Altee Dodge Aircraft Services Firewalll Battery Box Installation
Great Lakes Aero Products Single Piece Windshield
Hartzell Engine Technologies Alternator and Voltage Regulator Kit
J.P. Instruments Temperature Monitoring System with Fuel Flow EGT-701
Parker/Hannifin Corporation(Cleveland) Wheel and Brake Conversion
P Ponk Landing Gear Mod
Rosen Sunvisor Systems Cockpit Sun Visor Kit
Stene Aviation Cuff Leading Edge and Aileron gap seals
Stene Aviation Wing Tips and Quasar LED Lighting Landing and Taxi
Stene Aviation Split Seam Wing Strut Cuffs
Selkirk Aviation Fiberglass Extended Baggage Compartment
Selkirk Aviation Fiberglass Interior
Selkirk Aviation Composite Cowling
Avionics/Radios
Installed the following items new:
Garmin G500 Integrated Avionic Flight Display
Garmin GTN 650 Navigation System
Garmin GTX 345 with ADS-B In and Out Functionality
Garmin GMA 340 Audio Panel/Markers/Icom
Artex 345 ELT 406 Mhz
Additional Equipment
Installed the following items new:
Aero LED Strobe and Navigation Lighting
Aero LED Tail Beacon
Aero LED Landing and Taxi Lights
L/H and R/H Fuel Bladders
Heavy Duty Starter
Hight Output 70 Amp Alternator
Hawker Battery
Side Passenger window, Openable windows and Windshield
Mixture, Cowl Flap, Propeller Gov., Cowl Flap, Cabin Heat, Cabin Air control cables
All new flight control cables, pulleys, bushings and bearings.
Pilot and Co-Pilot Seat Rails
Aerostop Seat Locks
Headliner, Pilot, Co-Pilot and Rear Bench Seats re-upholstered with Burn Certified Materials
2550 Gross Wt
Empty WT 1725
825 Useful load.
New fuel bladders
