Key Specifications/Special Features
Description:
Rated power: 20W
Wi-Fi relay operation frequency: 2.4G
Communication distance: 1000m
EIRP FCC: 27 dBm; CE: 20 dBm
Gimbal controllable range +20 — -90
Angle range: 0.05
Operating current static state: 100mA
Input Voltage: 8V
Operating temperature: 0-40℃
Weight: 158g(included camera)
Size(including damping device): 60mm*70mm*85mm: :
Intelligent flight battery capacity: 2500mAh
Voltage: 11.1V
Battery type: Li-Po Battery
Energy: 27.75Wh
Net weight: 190g
Operating temperature: 0-40℃
Max charging power: 50W
Battery life: 20mins
Discharging temperature: 0-40℃
Quadcopter weight (Including battery and propellers): 550g
Take off weight: 1kg
Max ascent speed: 10m/s
Max descent speed: 5m/s
Max speed: 120km/s
Max altitude above sea level: 4km
Max flight time: 20-25 minutes
Operating temperature: 0-40℃
GPS mode: GPS/GLonASS Dual Mode
Max rotating angular velocity: 180 deg
Hover accuracy(safety fly mode): 1m
Wheelbase: 280mm
Diagonal size (including propellers) 295mm
Propeller type: 6030
Motor specs: 2204
Live view mobile App:
EIRP: 100 mW
Power spectral density: 6.9mW/MHz
Operating frequency: 2.4GHz ISM
Live view quality: 480P @ 25fps
Latency: < 200ms
Required operating systems: iOS 8.0 or later
Android 4.1.2 or later
Recommended Devices
•iOS
•Android
Camera(suitable for club camera)) Sensor SONY IMX078
Lens HD optical glass aspheric lens/F2.8 /150°wide angle
ISO Range video:1600/400 Photo:400/200/100
Shutter speed: Auto
Image Max size: 12.4M(4072 × 3044)
Still photography modes: Auto
Video recording modes: 1920*1080P 24/25/30FPS
1280*720P: 50/60FPS
