The drone XEagle Advanced
Aircraft
Weight (Including Battery And Propellers) 1270g
Max Dimension(Excluding Propellers) 290mm*290mm*180mm
Max Dimension(Including Propellers) 490mm*490mm*185mm
Diagonal Size 350mm
Max Ascent Speed 3m/s
Max Descent Speed 1.5m/s
Hover Accuracy Vertical: +/- 0.5m
Horizontal:+/- 1m
Max Follow Speed 15m/s
Max Flight Altitude 5000m
Max Flight Time about 22 mins
Operating Temperature - 10°C to 40°C
GPS Mode GPS/GLonASS Dual Mode
Camera
Sensor 1/2.3 CMOS
Lens Angle Horizontal: 105°
Diagonal:140°
Aperture F2.8
iSO Range 100-1600
Image Max Size 4000*3000
Working Modes Normal Recording,Normal Shoot , Time-lapse video, Delayed Shoot, 11 Burst
Video Recording Modes 4K@24fps
2.5K@30fps
1080P@60fps
720P@120fps
Supported File Formats File System:FAT32
Video Format: MP4
Image formats:JPG
Gimbal
Pitch Controllable Range -90° to +30°
Stabilization Three-Axis: Pitch , Roll and Yaw
Smart Watch
Operating Frequency 430-460MHz/910-940MHz
Max Control Distance 300m
Operating Temperature -10°C to 40°C
Battery 3.7V,450 mAh LiPo
Working Current/Voltage 0.2A/5V
Charging Time about 1 hour
Battery Charger
Input voltage 100-240V
Output voltage 12.6 V
Max Charging Power 50W
Intelligent Battery
Capacity 5200 mAh
Voltage 11.1V
Battery Type LiPo 3S
Energy 57.7 Wh
Net Weight 370g
Operating Temperature 0°C to 40°C
Charging Time 60-90 Mins
Remote Controller
Operating Frequency 5.8G
Max Control Distance 1000m
Operating Temperature 0°C to 40°C
Battery 3.7V 5000mAh LiPo
Image Transmission
Method WIFI
Operating Frequency 2.4G
Max Transmission Distance 500m (Depending on environment)
Video Resolution VGA
