Key Specifications/Special Features
Nominal Voltage
14.8V
Nominal Capacity
6000mAh(0.2C discharge)
Size
40*45*135 mm OR as customer request
Weight
332g
Composed Type
4S
Max Charge protection Voltage
14.8V
Cut-off Discharge Voltage
12V
Charging Current
0.2C~1C
Charging Time
2H
Charge Method
CC-CV
(constant current and contant voltage )
Max Discharge Current
25C
Recharge Cycle Life
800times
Working Temperature
Charge
0~45°C,45~85%RH
Dis-charge
-20~60°C,45~85%RH
StorageTemperature
One month
-20~60°C,45~85%RH
and Humidity
Three months
-20~45°C,45~85%RH
One year
-20~25°C,45~85%RH
Protection Fuctions
Over charge, Over discharge,
Over load, Short Circuit
Warranty
12months
