Key Specifications/Special Features
Charge voltage
12.6V
Nominal voltage
11.1V
Nominal capacity
5000mAh @ 0.2C Discharge
Lowest capacity
5000mAh @ 0.2C Discharge
Charge current
Standard Charging: 0.2C
Rapid charge: 1.0C
Standard Charging method
0.2C CC(constant current) charge to 12.6V, then CV(constant voltage 12.6V) charge till charge current decline to ≤0.05C
Charging time
Standard Charging: 5~7 hours(Ref.)
Rapid charge: 1.5~2.5 hours(Ref.)
Max charge current
1.0 C
Max discharge current
20 C
Discharge cut-off voltage
9.0V
Operating temperature
Charging: 0℃~45℃
Discharging: 0℃~45℃
Storage temperature
-10℃~ +45℃
Cell Dimension
Thickness: 20.6mm Max
Width: 45.3mm Max
Length: 135.5mm Max (not including tabs)
