The FPV’ers Quadcopter
The XuGong v2/Pro was designed by FPVers, for FPVers.
Designed for fully immersive flight, delivering high-quality, stabilized video footage, from a tailor-made aerial platform.
PRODUCT SPECIFICATIONS
Retail Price ($USD): $199 (frame + Electronics) + $199 (Gimbal)
Initial Release Date: Dec 2014
Max. Prop Size: 10 Inch
OSD: EzOSD-based, with Multicopter additions
Flight Controller: DJI Naza Lite, -M, v2 recommended, others supported
GPS: Naza GPS pickoff (Position + static Magnetometer)
Camera Switch: Manual, between Flight Cam, and GoPro, with auto-failover
Camera Power: 1.5A for GoPro, FlightCam powered from Video Tx
Flight Cam: Bracket to mount FatShark CMOS 600TVL + others (optional accessory)
Weight: AUW, RTF, ~1.5kg (typical)
Folded Size: 24cm W x 30cm L x 14cm H
Suitable Battery: 5200mAh 4s 10C recommended (for 20 minute flight times)
Suitable Motors: 2212/920kV, DJI E300, or Tiger AirGear 350
Flight Time: Typ. 20 min
