Unmanned Systems

This unmanned aerial vehicle was specifically designed for performing aerial photography. The unmanned aircraft allows you to get specified-altitude aerial photography of an area and receive the GPS location of objects of interest in order to perform the following tasks:

Aerial photography

Emergency monitoring

Real estate stocktaking

Mapping

Layout plan

Promo shooting

High-precision agriculture

Land reclamation

Livestock control

Land-use planning and monitoring

Forest stocktaking

Operation

All you need to do for the flight is to assign a flight path to the UAV, and it will do the rest of it for you. The unmanned aircraft is launched, executes an en-route flight and lands automatically. After that you just need to download highly detailed photos geotagged by GPS to your favourite application for photomaps, orthophotomaps, and DTMs creation. There are complete telemetry data for every shot – geographic coordinates of the central point, photography altitude and angle, and aircraft velocity/roll/pitch. In case of hard landing the wings are automatically detached from the centre section in order to mitigate the risk of damage to the UAV elements.

Photobot technical specifications:

Flight duration – 4 h;

Velocity range – 65 ÷ 120 km/h;

Radio channel distance – 70 km;

Maximum flying distance – min 360 km;

UAV weight – 4,5 kg;

Wingspan – 3,5 m;

Operational height – 50 ÷ 500 m;

Flight ceiling – min 3600 m;

Deployment time – 10 min.;

Operating conditions

wind velocity up to 15 m/s,

operating temperature range –30°С to +30°С,

moderate rain or snow;

Launching – elastic catapult;

Landing – with a parachute in automatic or semiautomatic mode;

Ground for takeoff and landing – 100 х 100 m;

Flight operation mode - automatic or semiautomatic;

Automatic self-diagnosis of ground and on-board equipment.
