The Rapidly Deployed Aerial Surveillance System (RDASS) Precision by Leptron UAS, Inc. is a vertical takeoff and landing multirotor platform used for stability, versatility and professional-grade remote sensing. The RDASS Precision model offers the same aerodynamic aircraft design as the RDASS HD, but it integrates a military-grade autopilot system with precision GPS and an advanced inertial navigation system. The RDASS is commanded from Leptron's Precision Ground Control Station (PGCS) that supports autonomous flight operations with the option of taking direct control at any time. The PGCS also offers the pilot superior situational awareness by displaying aircraft position on a moving map and real-time video from the aircraft's camera(s).
The RDASS camera mounting system accepts Leptron stabilized or fixed gimbal configurations. Each gimbal is perfectly balanced to minimize power consumption to optimize in-air performance. Additionally, the RDASS Precision can be equipped with navigation LEDs, red and blue strobe lights, and additional video viewing stations. With dozens of user defined system configurations available, the RDASS Precision is an ideal choice for law enforcement and military operations.
Platform Type
Rotor Tip to Rotor Tip Dimensions
Operating Temperature
Take-off Weight
Weight without Battery
Hovering Accuracy (GPS Mode)
Maximum Yaw Angular Velocity
Maximum Tilt Angle
Maximum Horizontal Flight Velocity
Wind Limits
Vertical Speed Limits
Supported Flight Battery
Operational Ceiling
Maximum Payload
Operational Range
Maximum Power Consumption
Multi-Rotor (four fixed-pitch rotors)
31 1/2 inches (80.1 cm)
-10°C – 50°C
7 lbs. 13 oz. (3539g)
5 lbs. (2269 g)
Vertical: ±31 in. (0.8 m) Horizontal: ±98 in. (2.5 m)
180°/s
35°
35 mph (30 knots, 15 m/s)
35 mph (30 knots, 15 m/s) continuous or gusts
of 25 mph (22 knots, 11 m/s)
800 feet/min. (4.1 m/s)
LiPo 6S
12,000 feet DA (3650 m)
1 lb. 8 oz. (680 g)
1.5 mile (2.4 km)
800 Watts (1.1 hp)
