The MicaSense RedEdge™ is an advanced, lightweight, multispectral camera optimized for use in small unmanned aircraft systems. RedEdge™ provides accurate multi-band data for agricultural remote sensing applications.
RedEdge™ is much more than just a camera, sharing more design features with Earth imaging satellites than it does with standard consumer cameras. Industrial imaging sensors provide high dynamic range in varying lighting conditions while removing artifacts commonly seen in drone video and imagery. Coupled with MicaSense Data Services, RedEdge™ provides a complete imaging, processing, and analysis system ready for integration with any platform.
Need a closer look? Unplug your RedEdge™ and go handheld. An integrated shutter button lets you take close-ups of areas of interest, and with the optional GPS module, maintain geo-tagging and timestamping of all of your multispectral images.
Weight
Dimensions
External Power
Spectral Bands
Ground Sample Distance
Capture Rate
Interface
Field of View
150 g (5.3 oz.)
12.1 cm x 6.6 cm x 4.6 cm (4.8 in. x 2.6 in. x 1.8 in.)
5.0 V DC, 4 W nominal
Blue, green, red, red edge, near IR (narrowband)
8.0 cm/pixel (per band) at 120 m (~400 ft.) AGL
1 capture per second (all bands), 12-bit RAW
Serial, Ethernet, GPS
47.2° HFOV
