Fly more days, fly more missions, achieve construction grade data with minimum downtime.
The DATAhawk Survey Drone has many benefits when it comes to overall performance including larger sensors, better wind performance and gimballed cameras are key factors that the DATAhawk benefits from.
Providing easy acquisition of accurate geodata for survey mapping and GIS professionals, this survey drone will automatically convert your high-res data into geo-referenced 2D orthomosiacs, 3D models and point clouds giving fast and reliable results... every flight.
DATAhawk Specifications
Specification Lite Standard High Altitude
Take off weight 1995g 2150g 2200g
Livery No Yes Optional
Wingspan 1164mm 1164mm 1330mm
Wing Area 47 dm2 47 dm2 56dm2
Visibility Range (Normal Eyesight) 750m 750m 850m
Full Pilot Control (Automatic, Assisted, Manual) Yes Yes Yes
Waypoint Routing Yes Yes Yes
Waypoint Redirection in Flight Yes Yes Yes
Ballistic Parachute (Safety + Vertical recovery Yes Yes Yes
Width / Length RTF 117 cm x 75 cm - -
Height With/Without Wingtips 115mm / 140mm 115mm / 140mm 115mm / 140mm
Primary Material EPP Foam, Carbon Composites EPP Foam EPP Foam
Propulsion Brushless 360W Axi motor. Brushless 360W Axi motor. Brushless 360W Axi motor.
Electric Pusher Propeller 9 x 6 9 x 6 9 x 6, 10 x 7
Launch Method Hand Launch/ Airdock Launch Hand Launch/ Airdock Launch Hand Launch/ Airdock Launch, ZipLine Launch
Battery 2 x 11.1 V, 4 000 mAh 2 x 11.1 V, 4 000 mAh 2 x 11.1 V, 4 000 mAh
Gimbaled Camera Ungimballed Roll Axis gimbal Roll Axis gimbal
Camera APSC - C 23.2x15.4 TBC Sony QX1 25 focus points 20.1Mp Sony QX1 25 focus points 20.1Mp
Camera Operation Manual/Automatic Manual/Automatic Manual/Automatic
Camera Resolution 125/400ft TBC 3.2cm 3.2cm
Project Management Yes Yes Yes
Mission Planning Multiple Flights Multiple Flights Multiple Flights
Automated Pre-Flight Checks Yes Yes Yes
Automatic Take Off, Flight and Landing Yes Yes Yes
Autonomous Camera Triggering Yes Yes Yes
Automated Fail-Safe Routines Yes Yes Yes
User Controlled Fail-Safe Commands Yes Yes Yes
Automated Post-Flight Checks Yes Yes Yes
Endurance < 45mins < 45mins < 45mins
Range 20km 20km 20km
Cruise Speed 19m/s 19m/s 21m/s
Max Cruise Speed 25m/s 25m/s 28m/s
Maximum Ceiling 3000ft 3000ft 10000ft
Recommended Cruise Height AGL 120m / 400ft 120m / 400ft 120m / 400ft
Max Recommended Cruise AGL 2000ft AGL 2000ft AGL 600ft AGL
Max Wind (at Cruise) 55kmh/35mph 55kmh/35mph 55kmh/35mph
Pre-Flight Setup Time 5 Minutes 5 Minutes 8 Minutes
Take off Type Hand/Airdock Hand/Airdock Hand/Airdock/ZipLine
Take off Angle 24 deg 25 deg 17 deg
Landing Type Parachute / Belly Landing Parachute / Belly Landing Parachute / Belly Landing
Auto Landing Angle 9 deg 9 deg 9 deg
Manual Landing Angle 0 to 30deg 0 to 30deg 0 to 30deg
