DEscriptION
PTP-02 Pan-Tilt Platform. PTP-02 is fully compatible with our GCS (Ground Control Station) of ACS (Automatic Control System of moving objects), it can be combined with other systems as well.
PTP-02 is a powerful manipulator working on very high accuracy and high angle speed drives with feedback coupling.
This device is designed for fast moving object tracking, long distance moving objects surveillance. PTP-02 can operate on moving objects. Device can handle equipment up to 30 kg.
PTP-02 can be upgraded with CCD cameras with large zoom lens, cooled thermographic cameras, laser telemeters, directional antenna and spotlight. There’s socket in upper body of device designed for PC-104 placement.
Device can be used as a turret in guidance system, when placed on moving objects .
PTP-02 has 12 digital channels /5А, 4 power supply channels /10А and 1 Ethernet channel (1000baseT or 2 100baseT).
