Aircraft
Main Rotor Dia 143mm
Overall (L x W x H) 221x205x117mm
Weight 464g(Battery excluded)
Remote Controller DEVO 7
Receiver DEVO-RX717
Main Controller FCS-250
Transmitter TX5834(FCC)/TX5835(CE)(OSD included)
Brushless Motor WK-WS-28-014A(CW/CCW)
Brushless ESC F210 ESC
Battery 11.1V 2200mAh 25C 3S Li-Po
Flight Time 10~12mins
Working Temperature -10℃~+40℃
Camera(800TVL)
Horizontal Resolution 800TVL
System Commitee PAL/NTSC
Video Out 1.0Vp-p/75
Power Input DC 12V
DEVO 7 Remote Controller
Frequency 2.4GHz DSSS
Output Power ≤100mW
Current drain ≤230mA(100mW)
Power Supply 5# Battery 8x1.5V or NiMH 8x1.2V 1600-2000mAh
Output Pulse 1000-2000mS(1500Ms Neutral)
