Aircraft Specifications
Main Rotor Dia 143mm
Overall (L x W x H) 236x205x102mm
Weight 446g (Battery excluded)
Remote Controller DEVO F7/DEVO 7
Receiver DEVO-RX710(R)
Main Controller FCS-Runner 250(R)
Emitter TX5816(FCC)/TX5817(CE)
OSD Runner 250 OSD(R)
Brushless Motor WK-WS-28-014(CW/CCW)
Brushless ESC Runner 250
Battery 11.1V 2200mAh 25C 3S LiPo
Flight Time 11~12mins
Working Temperature -10℃~ +40℃
Video Resolution 19201080P 60FPS
Micro SD card Max 64G
Video Format MOV
Photo 40003000 Pixels
Photo Format JPG
Power Input DC 5V
Camera(800TVL)
Horizontal Resolution 800TVL
System Commitee PAL/NTSC
Video Out 1.0Vp-p/75Ω
Power Input DC 12V
TX5816(FCC) / TX5817(CE) Emitter
5.8G wireless image transmission
TX5816(FCC) B section: 4 channels
TX5817(CE) B section: 8 channels
TX5816(FCC) output power ≤200mW
TX5817(CE) output power ≤25mW
